TEXAS INSTRUMENTS SN74LV540APW 逻辑芯片, 缓冲器/驱动器, 三态, 八路, 20TSSOP
This buffer and line driver from Texas Instruments is used to amplify an analog or digital signal by driving the input to the transmission line. With a 3-state output, this is power management at its best. This line driver has a minimum operating temperature of -40 °C and a maximum of 125 °C. This device comes in tube packaging. It has 8 channels per chip. This inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 5.5 V.
电源电压DC 2.00V ~ 5.50V
输出接口数 8
电路数 1
通道数 8
针脚数 20
位数 8
传送延迟时间 8.50 ns
电压波节 5.00 V, 3.30 V, 2.50 V
输出电流驱动 -1.00 mA
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
长度 6.6 mm
宽度 4.5 mm
高度 1.05 mm
封装 TSSOP-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
SN74LV540APW TI 德州仪器 | 当前型号 | 当前型号 |
SN74LV540APWRG4 德州仪器 | 完全替代 | SN74LV540APW和SN74LV540APWRG4的区别 |
SN74LV540APWR 德州仪器 | 类似代替 | SN74LV540APW和SN74LV540APWR的区别 |
SN74LV540APWT 德州仪器 | 类似代替 | SN74LV540APW和SN74LV540APWT的区别 |
