SLF6028 系列磁性屏蔽线绕扼流圈薄型表面安装磁性屏蔽电源线路电感器,用于减少 EMC 应用包括便携式电话机、个人计算机、硬盘驱动器及其他电子设备 ### TDK 非标准 SMT 电感器(扼流圈)
固定器
得捷:
FIXED IND 33UH 1.1A 177.6MOHM SM
立创商城:
33uH ±20% 177.6mΩ
欧时:
TDK SLF 系列 33 μH 绕线贴片电感器 SLF6028T-330MR69-PF, ±20%容差, 1.1A Idc, 148mΩ最大直流电阻
e络盟:
表面贴装功率电感器, 绕线铁氧体, SLF Series, 33 µH, ± 20%, 0.1776 ohm, 690 mA
艾睿:
Make any circuit look clean and compact using this power SLF6028T-330MR69-PF surface mount inductor from TDK. This SMD inductor has an operating temperature range of -40 °C to 105 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device utilizes wirewound technology. This product is 6.2 mm long, 3 mm tall and 6.2 mm deep. It has a tolerance of 20%. Its test frequency is 100K Hz. It has an inductance of 33u H. This SMD inductor has a maximum DC current of 1.1Typ A with a maximum resistance of 177.6m Ohm.
安富利:
Ind Power Shielded Wirewound 33uH 20% 100KHz 1.1A 2424 T/R
Chip1Stop:
Ind Power Shielded Wirewound 33uH 20% 100KHz 1.1A 2424 T/R
Verical:
Inductor Power Shielded Wirewound 33uH 20% 100KHz Ferrite 1.1A 0.1776Ohm DCR 2424 T/R
Electro Sonic:
Inductor Power Shielded Wirewound 33uH 20% 100KHz Ferrite 1.1A 177.6mOhm DCR 2424 T/R
Win Source:
33μH Shielded Wirewound Inductor 1.1A 177.6 mOhm Max Nonstandard
额定电流 1.1 A
容差 ±20 %
电感 33 µH
产品系列 SLF
阻值偏差 ±20 %
屏蔽 Yes
电感公差 ±20 %
测试频率 100 kHz
电阻DC) ≤177.6 mΩ
额定电流DC 690 mA
工作温度Max 85 ℃
工作温度Min -20 ℃
电阻DC Max 0.1776 Ω
安装方式 Surface Mount
封装 SMD
长度 6.0 mm
宽度 6 mm
高度 2.8 mm
封装 SMD
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 1000
制造应用 Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SLF6028T-330MR69-PF TDK 东电化 | 当前型号 | 当前型号 |
SLF6028T-330MR69 东电化 | 功能相似 | SLF6028T-330MR69-PF和SLF6028T-330MR69的区别 |
