16位缓冲器/驱动器,具有三态输出 16-BIT BUFFERS/DRIVERS WITH 3-STATE OUTPUTS
These 16-bit buffers and bus drivers provide a high-performance bus interface for wide data paths.
The 3-state control gate is a 2-input AND gate with active-low inputs so that if either output-enable OE1\ or OE2\\\\ input is high, all corresponding outputs are in the high-impedance state.
To ensure the high-impedance state during power up or power down, OE\ should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.
The SN54AHCT16540 is characterized for operation over the full military temperature range of -55°C to 125°C. The SN74AHCT16540 is characterized for operation from -40°C to 85°C.
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74AHCT16540DL TI 德州仪器 | 当前型号 | 当前型号 |
SN74AHCT16540DGVR 德州仪器 | 完全替代 | SN74AHCT16540DL和SN74AHCT16540DGVR的区别 |
SN74AHCT16540DGGR 德州仪器 | 类似代替 | SN74AHCT16540DL和SN74AHCT16540DGGR的区别 |
74AHCT16540DLRG4 德州仪器 | 类似代替 | SN74AHCT16540DL和74AHCT16540DLRG4的区别 |
