SRR6603-151ML

BOURNS  SRR6603-151ML  表面贴装功率电感器, SRR6603系列, 150 µH, ± 20%, 屏蔽, 0.59 ohm, 260 mA

Inductor Power Shielded Wirewound 150uH 20% 100KHz 40Q-Factor Ferrite 260mA 590mOhm DCR T/R

得捷:
FIXED IND 150UH 260MA 590MOHM SM

e络盟:
BOURNS  SRR6603-151ML  表面贴装功率电感器, SRR6603系列, 150 µH, ± 20%, 屏蔽, 0.59 ohm, 260 mA

艾睿:
This power SRR6603-151ML surface mount inductor from Bourns is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has a minimum operating temperature of -55 °C and a maximum of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It has an inductance of 150u H. This SMD inductor has a maximum DC current of 260m A with a maximum resistance of 590m Ohm. This product is 6.6 mm long, 3 mm tall and 4.4 mm deep. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 9MTyp Hz. It has a tolerance of 20%. This device is made with wirewound technology.

安富利:
Ind Power Shielded Wirewound 150uH 20% 100KHz 40Q-Factor Ferrite 260mA T/R

Verical:
Inductor Power Shielded Wirewound 150uH 20% 100KHz 40Q-Factor Ferrite 0.26A 0.59Ohm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 150uH 20% 100KHz 40Q-Factor Ferrite 260mA 590mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 150uH 20% 100KHz 40Q-Factor Ferrite 260mA 590mOhm DCR T/R
