SRR6603-680ML

BOURNS  SRR6603-680ML  表面贴装功率电感器, SRR6603系列, 68 µH, ± 20%, 屏蔽, 0.29 ohm, 400 mA

68µH Shielded Wirewound Inductor 400mA 290mOhm Max Nonstandard

立创商城:
68uH ±20% 400mA 290mΩ

得捷:
FIXED IND 68UH 400MA 290MOHM SMD

贸泽:
Fixed Inductors 68uH 20% SMD 6603

e络盟:
功率电感SMD, 68 µH, 400 mA, 屏蔽, 170 mA, SRR6603系列, 6.6mm x 4.4mm x 3mm

艾睿:
An ideal space-saving electronic component is this power SRR6603-680ML surface mount inductor from Bourns. This SMD inductor has an operating temperature range of -55 °C to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 15MTyp Hz. This product is 6.6 mm long, 3 mm tall and 4.4 mm deep. This device utilizes wirewound technology. It has an inductance of 68u H. This SMD inductor has a maximum DC current of 400m A with a maximum resistance of 290m Ohm. It has a tolerance of 20%.

安富利:
Ind Power Shielded Wirewound 68uH 20% 100KHz 40Q-Factor Ferrite 400mA T/R

Verical:
Inductor Power Shielded Wirewound 68uH 20% 100KHz 40Q-Factor Ferrite 0.4A 0.29Ohm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 68uH 20% 100KHz 40Q-Factor Ferrite 400mA 290mOhm DCR T/R
