单缓冲器/驱动器,具有漏极开路输出 SINGLE BUFFER/DRIVER WITH OPEN-DRAIN OUTPUT
This single buffer/driver is designed for 1.65-V to 5.5-V VCC operation.
The output of the SN74LVC1G07 device is open drain and can be connected to other open-drain outputs to implement active-low wired-OR or active-high wired-AND functions. The maximum sink current is 32 mA.
The SN74LVC1G07 is available in a variety of packages, including the ultra-small DPW package with a body size of 0.8 mm × 0.8 mm.
得捷:
IC BUF NON-INVERT 5.5V 5DSBGA
立创商城:
SN74LVC1G07YZPR
德州仪器TI:
Single 1.65-V to 5.5-V buffer with open-drain outputs
贸泽:
缓冲器和线路驱动器 SNGL Buffer/Driver
艾睿:
Leading the input to the transmission line this SN74LVC1G07YZPR buffer and line driver by Texas Instruments will amplify digital and analog signals. With an open drain output, this is power management at its best. This line driver has a minimum operating temperature of -40 °C and a maximum of 85 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This non-inverting device has a typical operating supply voltage of 1.8|2.5|3.3|5 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 5.5 V. It has 1 channels per chip.
安富利:
Buffer/Driver 1-CH Non-Inverting Open Drain CMOS 5-Pin DSBGA T/R
Chip1Stop:
Buffer/Driver 1-CH Non-Inverting Open Drain CMOS 5-Pin DSBGA T/R
Verical:
Buffer/Driver 1-CH Non-Inverting Open Drain CMOS 5-Pin DSBGA T/R
电源电压DC 1.65V min
输出接口数 1
通道数 1
位数 1
传送延迟时间 3.50 ns
电压波节 5.00 V
逻辑门个数 1
输入数 1
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.65 V
安装方式 Surface Mount
引脚数 5
封装 DSBGA-5
长度 1.4 mm
宽度 0.9 mm
高度 0.3 mm
封装 DSBGA-5
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
