SRP1040-5R6M

5.6uH ±20% 7A

Inductor Power Shielded Wirewound 5.6uH 20% 100KHz Iron 7A 16mOhm DCR T/R

得捷:
FIXED IND 5.6UH 7A 16 MOHM SMD

艾睿:
Use this power SRP1040-5R6M surface mount inductor from Bourns to make any circuit look clean and compact. This SMD inductor has an operating temperature range of -55 °C to 150 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has a tolerance of 20%. This product is 11.8 mm long, 4.2 mm tall and 10.5 mm deep. Its test frequency is 100K Hz. This device utilizes wirewound technology. It has an inductance of 5.6u H. This SMD inductor has a maximum DC current of 7 A with a maximum resistance of 16m Ohm.

安富利:
Ind Power Shielded Wirewound 5.6uH 20% 100KHz Iron 7A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 5.6uH 20% 100KHz Iron 7A 16mOhm DCR T/R

Verical:
Inductor Power Shielded Wirewound 5.6uH 20% 100KHz Iron 7A 0.016Ohm DCR T/R

Newark:
# BOURNS  SRP1040-5R6M  Surface Mount Power Inductor, SRP1040 Series, 5.6 µH, 7 A, 12 A, Shielded, 0.016 ohm

Online Components:
Inductor Power Shielded Wirewound 5.6uH 20% 100KHz Iron 7A 16mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 5.6uH 20% 100KHz Iron 7A 0.016Ohm DCR T/R

Win Source:
FIXED IND 5.6UH 7A 16 MOHM SMD
