SN74HCT125DRG4

Buffer/Line Driver 4CH Non-Inverting 3-ST CMOS 14Pin SOIC T/R

Operating Voltage Range of 4.5 V to 5.5 V

High-Current Outputs Drive Up To 15 LSTTL Loads

Low Power Consumption, 80-µA Max ICC

Typical tpd = 12 ns

±6-mA Output Drive at 5 V

Low Input Current of 1 µA Max

Inputs Are TTL-Voltage Compatible

High-Current 3-State Outputs Drive Bus Lines or Buffer Memory Address Registers

艾睿:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SOIC T/R

Verical:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SOIC T/R
