八路缓冲器/驱动器,具有三态输出 OCTAL BUFFER/DRIVER WITH 3-STATE OUTPUTS
缓冲器,非反向 1 元件 8 位每元件 三态 Output 20-SOIC
立创商城:
SN74LVC541AQDWREP
德州仪器TI:
Enhanced product 8-ch, 2-V to 3.6-V buffers with 3-state outputs
得捷:
IC BUF NON-INVERT 3.6V 20SOIC
贸泽:
缓冲器和线路驱动器 Mil Enhance Octal Buffer/Driver
艾睿:
Leading the input to the transmission line this SN74LVC541AQDWREP buffer and line driver by Texas Instruments will amplify digital and analog signals. With a 3-state output, this is power management at its best. This line driver has a minimum operating temperature of -40 °C and a maximum of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This non-inverting device has a typical operating supply voltage of 2.5|3.3 V. Its minimum operating supply voltage of 2 V, while its maximum is 3.6 V. It has 8 channels per chip.
安富利:
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin SOIC T/R
Chip1Stop:
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin SOIC T/R
Win Source:
IC BUF NON-INVERT 3.6V 20SOIC / Buffer, Non-Inverting 1 Element 8 Bit per Element 3-State Output 20-SOIC
电源电压DC 2.00V ~ 3.60V
输出接口数 8
传送延迟时间 5.10 ns
电压波节 3.30 V, 2.70 V
输出电流驱动 -1.00 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 2V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 20
封装 SOIC-20
长度 12.8 mm
宽度 7.52 mm
高度 2.35 mm
封装 SOIC-20
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LVC541AQDWREP TI 德州仪器 | 当前型号 | 当前型号 |
SN74LVC541ADWR 德州仪器 | 类似代替 | SN74LVC541AQDWREP和SN74LVC541ADWR的区别 |
SN74LVC541ADW 德州仪器 | 类似代替 | SN74LVC541AQDWREP和SN74LVC541ADW的区别 |
SN74LVC541AQDWRQ1 德州仪器 | 类似代替 | SN74LVC541AQDWREP和SN74LVC541AQDWRQ1的区别 |
