单位双电源总线收发器 SINGLE BIT DUAL SUPPLY BUS TRANSCEIVER
电压电平 转换器 双向 1 电路 1 通道 500Mbps 6-DSBGA
得捷:
IC TRANSLTR BIDIRECTIONAL 6DSBGA
立创商城:
SN74AVCH1T45YZPR
德州仪器TI:
Single-Bit Dual-Supply Bus Transceiver with Configurable Voltage Translation and 3-State Outputs
艾睿:
The Texas Instruments SN74AVCH1T45YZPR level translator can control and allow the proper input voltage into your electronic circuits. With a 3-state output, this is power management at its best. This level shifter has a minimum operating temperature of -40 °C and a maximum of 85 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This device has a typical operating supply voltage of 1.8|2.5|3.3 V. Its minimum operating supply voltage of 1.2 V, while its maximum is 3.6 V.
安富利:
Voltage Level Translator 6-Pin DSBGA T/R
Verical:
Voltage Level Translator 1-CH Bidirectional 6-Pin DSBGA T/R
Newark:
# TEXAS INSTRUMENTS SN74AVCH1T45YZPR Bus Transceiver, AVC Family, 1 Input, 1bit, 12 mA, 2.8 ns, 1.2 V to 3.6 V, BGA-6
DeviceMart:
IC BUS TRANSCVR TRI-ST 6DSBGA
Win Source:
Voltage Level Translator Bidirectional 1 Circuit 1 Channel 500Mbps 6-DSBGA, 6-WCSP 1.4x0.9
电源电压DC 1.20V ~ 3.60V
输出接口数 2
输出电流 12 mA
电路数 1
通道数 1
位数 1
传送延迟时间 2.80 ns
电压波节 3.30 V
输入数 1
工作温度Max 85 ℃
工作温度Min -40 ℃
输出通道数 1
电源电压 1.2V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 1.2 V
安装方式 Surface Mount
引脚数 6
封装 DSBGA-6
封装 DSBGA-6
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74AVCH1T45YZPR TI 德州仪器 | 当前型号 | 当前型号 |
SN74AVCH1T45DBVR 德州仪器 | 完全替代 | SN74AVCH1T45YZPR和SN74AVCH1T45DBVR的区别 |
SN74AVC1T45DCKR 德州仪器 | 完全替代 | SN74AVCH1T45YZPR和SN74AVC1T45DCKR的区别 |
SN74AVC1T45DCKT 德州仪器 | 完全替代 | SN74AVCH1T45YZPR和SN74AVC1T45DCKT的区别 |
