SN74AUP1T97YZPR概述

74AUP1T 系列,Texas Instruments### 74AUP 系列工业标准高级超低功耗 AUP 逻辑系列产品,用于超低功耗、体积小的逻辑解决方案,适用于 1.8 V 和混合 1.8 V / 3.3 V 电路应用。 AUP 逻辑系列提供以下特征:广泛的电压范围:0.8 至 3.6V 施密特触发器输入,用于高抗杂讯度 极低的动态功耗 增强型 ESD 保护 速度/功耗优化

逻辑类型Logic Type| 变换器 Translator \---|--- 电路数Number of Circuits| 3 输入数Number of Inputs| 电压 Voltage 电源电压VccVoltage - Supply| 电压 Voltage 静态电流IqCurrent - Quiescent Max| 输出高,低电平电流Current - Output High, Low| 3 低逻辑电平Logic Level - Low| 1 高逻辑电平Logic Level - High| 无/无 No/No 传播延迟时间@Vcc,CLMax Propagation Delay @ V, Max CL| 4.7ns Description & Applications| 2.3 V ~ 3.6 V 描述与应用| SINGLE-SUPPLY VOLTAGE-LEVEL TRANSLATOR WITH NINE CONFIGURABLE GATE LOGIC FUNCONS DESCRIPTION/ORDERING INFORMATION AUP technology is the industry"s lowest-power logic technology designed for use in battery-operated or battery backed-up equipment. The SN74AUP1T97 is designed for logic-level translation applications with input switching levels that accept 1.8-V LVCMOS signals, while operating from either a single 3.3-V or 2.5-V VCC supply. The wide VCC range of 2.3 V to 3.6 V allows the possibility of battery voltage drop during system operation and ensures normal operation between this range. Schmitt-trigger inputs ΔVT = 210 mV between positive and negative input transitions offer improved noise immunity during switching transitions, which is especially useful on analog mixed-mode designs. Schmitt-trigger inputs reject input noise, ensure integrity of output signals, and allow for slow input signal transition. The SN74AUP1T97 can be easily configured to perform a required gate function by connecting A, B, and C inputs to VCC or ground see Function Selection table. Up to nine commonly used logic gate functions can be performed. • Available in the Texas Instruments NanoStar™ TOP VIEW Packages • Single-Supply Voltage Translator • 1.8 V to 3.3 V at VCC = 3.3 V • 2.5 V to 3.3 V at VCC = 3.3 V • 1.8 V to 2.5 V at VCC = 2.5 V DRY OR DSF PACKAGE • 3.3 V to 2.5 V at VCC = 2.5 V TOP VIEW • Nine Configurable Gate Logic Functions • Schmitt-Trigger Inputs Reject Input Noise and Provide Better Output Signal Integrity • Ioff Supports Partial-Power-Down Mode With Low Leakage Current 0.5 µA • Very Low Static and Dynamic Power YFP OR YZP PACKAGE Consumption TOP VIEW • Pb-Free Packages Available: SON DRY or DSF, SOT-23 DBV, SC-70 DCK, and NanoStar WCSP • Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II • ESD Performance Tested Per JESD 22 – 2000-V Human-Body Model A114-B, Class II – 1000-V Charged-Device Model C101 • Related Devices: SN74AUP1T98, SN74AUP1T57, and SN74AUP1T58

SN74AUP1T97YZPR中文资料参数规格
技术参数

电源电压DC 2.30V ~ 3.60V

输出接口数 1

输出电流 4.00 mA

电路数 1

通道数 1

位数 3

传送延迟时间 3.50 ns

电压波节 2.50 V, 3.30 V

工作温度Max 85 ℃

工作温度Min -40 ℃

输出通道数 1

电源电压 2.3V ~ 3.6V

电源电压Max 3.6 V

封装参数

安装方式 Surface Mount

引脚数 6

封装 DSBGA-6

外形尺寸

长度 1.42 mm

宽度 0.31 mm

高度 0.918 mm

封装 DSBGA-6

物理参数

工作温度 -40℃ ~ 85℃ TA

其他

产品生命周期 Active

包装方式 Tape & Reel TR

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

海关信息

ECCN代码 EAR99

数据手册

SN74AUP1T97YZPR引脚图与封装图
SN74AUP1T97YZPR引脚图
SN74AUP1T97YZPR封装图
SN74AUP1T97YZPR封装焊盘图
在线购买SN74AUP1T97YZPR
型号: SN74AUP1T97YZPR
制造商: TI 德州仪器
描述:74AUP1T 系列,Texas Instruments ### 74AUP 系列 工业标准高级超低功耗 AUP 逻辑系列产品,用于超低功耗、体积小的逻辑解决方案,适用于 1.8 V 和混合 1.8 V / 3.3 V 电路应用。 AUP 逻辑系列提供以下特征: 广泛的电压范围:0.8 至 3.6V 施密特触发器输入,用于高抗杂讯度 极低的动态功耗 增强型 ESD 保护 速度/功耗优化
替代型号SN74AUP1T97YZPR
型号/品牌 代替类型 替代型号对比

SN74AUP1T97YZPR

TI 德州仪器

当前型号

当前型号

SN74AUP1T97YFPR

德州仪器

完全替代

SN74AUP1T97YZPR和SN74AUP1T97YFPR的区别

SN74AUP1T97YEPR

德州仪器

功能相似

SN74AUP1T97YZPR和SN74AUP1T97YEPR的区别
