触发器 Octal D-Type Flip- Flops
Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-SOIC 0.209", 5.30mm Width
得捷:
IC FF D-TYPE SNGL 8BIT 20SO
立创商城:
SN74HCT273ANSR
德州仪器TI:
Octal D-Type Flip-Flops With Clear
贸泽:
触发器 Octal D-Type Flip- Flops
艾睿:
Flip Flop D-Type Bus Interface Pos-Edge 1-Element 20-Pin SOP T/R
安富利:
Flip Flop D-Type Bus Interface Pos-Edge 1-Element 20-Pin SOP T/R
Chip1Stop:
Flip Flop D-Type Bus Interface Pos-Edge 1-Element 20-Pin SOP T/R
Verical:
Flip Flop D-Type Bus Interface Pos-Edge 1-Element 20-Pin SOP T/R
输出接口数 8
电路数 1
时钟频率 37 MHz
位数 8
输入电容 3 pF
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
安装方式 Surface Mount
引脚数 20
封装 SOP-20
长度 12.6 mm
宽度 5.3 mm
高度 1.95 mm
封装 SOP-20
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Not Recommended for New Designs
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
