六路D型触发器与Clear HEX D-TYPE FLIP-FLOPS WITH CLEAR
元件 D 型 位 正边沿 16-TFSOP(0.173",4.40mm 宽)
得捷:
IC FF D-TYPE SNGL 6BIT 16TVSOP
立创商城:
SN74LV174ADGVR
德州仪器TI:
Hex D-Type Flip-Flops With Clear
贸泽:
触发器 Hex D-Type Flip-Flop With Clear
艾睿:
Think of Texas Instruments&s; SN74LV174ADGVR flip flop device in the event you need to save or retrieve your circuit&s;s state information quickly. It has a single-ended output signal. This flip flop has a minimum operating temperature of -40 °C and a maximum of 85 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It has 6 channels per chip. This non-inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 5.5 V.
安富利:
Flip Flop D-Type Bus Interface Pos-Edge 1-Element 16-Pin TVSOP T/R
频率 180 MHz
电源电压DC 2.00V min
输出电流 12.0 mA
电路数 7
时钟频率 180 MHz
位数 6
电压波节 5.00 V, 3.30 V, 2.50 V
输入电容 1.7 pF
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 5.5V
安装方式 Surface Mount
引脚数 16
封装 TFSOP-16
长度 3.6 mm
宽度 4.4 mm
高度 1.05 mm
封装 TFSOP-16
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LV174ADGVR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LV174ADGVRG4 德州仪器 | 功能相似 | SN74LV174ADGVR和SN74LV174ADGVRG4的区别 |
SN74LV174ADGVRE4 德州仪器 | 功能相似 | SN74LV174ADGVR和SN74LV174ADGVRE4的区别 |
