八路透明D类锁存器具有三态输出 OCTAL TRANSPARENT D-TYPE LATCHES WITH 3-STATE OUTPUTS
D 型透明 1 通道 8:8 IC 三态 20-BGA MICROSTAR JUNIOR(4x3)
得捷:
IC OCT TRNSP D-TYP LATCH 20-BGA
艾睿:
This d-type SN74LVC573AZQNR low-level latch manufactured by Texas Instruments contains real time information and can be pushed through it once it is enabled. With a 3-state output, this is power management at its best. This latch has a minimum operating temperature of -40 °C and a maximum of 85 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 1.8|2.5|3.3 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 3.6 V.
安富利:
Latch Transparent 3-ST 8-CH D-Type 20-Pin BGA MICROSTAR JUNIOR T/R
Chip1Stop:
Latch Transparent 3-ST 8-CH D-Type 20-Pin BGA MICROSTAR JUNIOR T/R
Verical:
Latch Transparent 3-ST 8-CH D-Type 20-Pin BGA MICROSTAR JUNIOR T/R
Newark:
Latch, LVC Family, 74LVC573, Transparent, Tri State, 6.9 ns, 24 mA, BGA
Win Source:
IC OCT TRNSP D-TYP LATCH 20-BGA / D-Type Transparent Latch 1 Channel 8:8 IC Tri-State 20-BGA MICROSTAR JUNIOR 4x3
电源电压DC 2.00V ~ 3.60V
输出接口数 8
输出电流 24 mA
电路数 8
位数 8
传送延迟时间 7.50 ns
电压波节 3.30 V, 2.70 V, 2.50 V, 1.80 V
输出电流驱动 -1.00 mA
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 1.65 V
安装方式 Surface Mount
引脚数 20
封装 BGA-20
封装 BGA-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LVC573AZQNR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LVC573AGQNR 德州仪器 | 完全替代 | SN74LVC573AZQNR和SN74LVC573AGQNR的区别 |
