SN74LV175ANSR

翻两番D型触发器与Clear QUADRUPLE D-TYPE FLIP-FLOPS WITH CLEAR

The "LV175A devices are quadruple D-type flip-flops designed for 2-V to 5.5-V VCC operation.

These devices have a direct clear CLR\\\\ input and feature complementary outputs from each flip-flop.

Information at the data D inputs meeting the setup time requirements is transferred to the outputs on the positive-going edge of the clock CLK pulse.

Clock triggering occurs at a particular voltage level and is not directly related to the transition time of the positive-going edge of CLK. When CLK is at either the high or low level, the D input has no effect at the output.
