具有可配置的输出电压和三态输出的八路双电源总线收发器 OCTAL DUAL-SUPPLY BUS TRANSCEIVER WITH CONFIGURABLE OUTPUT VOLTAGE AND 3-STATE OUTPUTS
电压电平 转换器 双向 电路 8 通道 - 24-SSOP
得捷:
IC TRANSLTR BIDIRECTIONAL 24SSOP
立创商城:
SN74LVCC4245ADBR
德州仪器TI:
Octal Bus Transceiver With Adjustable Output Voltage and 3-State Outputs
贸泽:
Translation - Voltage Levels Tri-State Octal Bus
艾睿:
The Texas Instruments SN74LVCC4245ADBR level translator can control and allow the proper input voltage into your electronic circuits. With a 3-state output, this is power management at its best. This level shifter has an operating temperature range of -40 °C to 85 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This device has a typical operating supply voltage of 3.3/5 V. Its minimum operating supply voltage of 2.7/4.5 V, while its maximum is 5.5 V.
安富利:
Bus XCVR Single 8-CH 3-ST 24-Pin SSOP T/R
Chip1Stop:
Voltage Level Translator 24-Pin SSOP T/R
Verical:
Voltage Level Translator 8-CH Bidirectional 24-Pin SSOP T/R
DeviceMart:
IC BUS TRANSCEIVER 8BIT 24SSOP
电源电压DC 3.30 V, 5.50 V max
输出电流 24.0 mA
电路数 1
通道数 8
位数 8
传送延迟时间 2.70 ns
电压波节 5.00 V, 3.30 V
工作温度Max 85 ℃
工作温度Min -40 ℃
输出通道数 8
电源电压Max 5.5 V
电源电压Min 2.7V, 4.5V
安装方式 Surface Mount
引脚数 24
封装 SSOP-24
封装 SSOP-24
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LVCC4245ADBR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LVCC4245ADBRG4 德州仪器 | 完全替代 | SN74LVCC4245ADBR和SN74LVCC4245ADBRG4的区别 |
SN74LVC4245ADBR 德州仪器 | 类似代替 | SN74LVCC4245ADBR和SN74LVC4245ADBR的区别 |
SN74LVCC4245ADBRE4 德州仪器 | 类似代替 | SN74LVCC4245ADBR和SN74LVCC4245ADBRE4的区别 |
