TEXAS INSTRUMENTS SN74LV4040APW 逻辑芯片, 异步二进制计数器, 16TSSOP
The LV4040A devices are 12-bit asynchronous binary counters with the outputs of all stages available externally. A high level at the clear CLR input asynchronously clears the counter and resets all outputs low. The count is advanced on a high-to-low transition at the clock CLK input. Applications include time-delay circuits, counter controls, and frequency-dividing circuits.
These devices are fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the devices when they are powered down.
电源电压DC 2.00V ~ 5.50V
输出接口数 12
针脚数 16
时钟频率 185 MHz
位数 12
电压波节 5.00 V, 3.30 V, 2.50 V
输入数 1
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 16
封装 TSSOP-16
封装 TSSOP-16
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LV4040APW TI 德州仪器 | 当前型号 | 当前型号 |
SN74LV4040APWR 德州仪器 | 完全替代 | SN74LV4040APW和SN74LV4040APWR的区别 |
SN74LV4040ADGVR 德州仪器 | 完全替代 | SN74LV4040APW和SN74LV4040ADGVR的区别 |
SN74LV4040APWRG4 德州仪器 | 完全替代 | SN74LV4040APW和SN74LV4040APWRG4的区别 |
