SN74BCT126AD

具有三态输出翻两番总线缓冲器GATES QUADRUPLE BUS BUFFER GATES WITH 3-STATE OUTPUTS

description

The ′BCT126A bus buffer features independent line drivers with 3-state outputs. Each output is disabled when the associated output-enable OE input is low.

The SN54BCT126A is characterized for operation over the full military temperature range of –55°C to 125°C. The SN74BCT126A is characterized for operation from 0°C to 70°C.

• State-of-the-Art BiCMOS Design Significantly Reduces ICCZ

• ESD Protection Exceeds 2000 V Per MIL-STD-883C, Method 3015

• 3-State Outputs Drive Bus Lines or Buffer Memory Address Registers

• Package Options Include Plastic

   Small-Outline D Packages, Ceramic Chip Carriers FK and Flatpacks W, and Standard Plastic and Ceramic 300-mil DIPs J, N
