SL-115-T-11

Conn Socket Strip SKT 15POS 2.54mm Solder ST Thru-Hole

15 Position Receptacle Connector 0.100" 2.54mm Through Hole Gold

得捷:
CONN RCPT .100" 15POS GOLD PCB

立创商城:
2.54mm

艾睿:
This socket strip SL-115-T-11 header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This SKT connector&s;s 15 contacts that are made out of beryllium copper and plated with gold over nickel. It has a socket type gender. This is a 1-row connector. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 1 A. This product comes packaged in bulk, so the parts will be stored loosely. This product is 38.1 mm long, 3.35 mm tall and 2.54 mm deep. SL-115-T-11 is housed in black polyester. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Socket Strip SKT 15 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Socket Strip SKT 15 POS 2.54mm Solder ST Top Entry Thru-Hole Bulk
