电源监控+ PWM Power Supply Supervisor + PWM
DESCRIPTION
The SG6108 controller is designed for desktop PC switching mode power supplies. It provides everything
necessary to monitor and control the output of the power supply. Remote ON/OFF control, power good circuitry, over-voltage protection, over-power protection, and over-current protection are all included. The SG6108 directly senses all the output rails for over voltage conditions without requiring external dividers.
FEATURES
PC half-bridge or 494 power supply supervisor + PWM
Highly Integrated and Few external components required
Over voltage protection 3.3V/5V/12V two 12V
Under voltage protection 3.3V/5V/12V two 12V
Under voltage protection for –12V and/or –5V
Over current protection 3.3V/5V/12V two 12V
Over power protection
Short circuit protection
Power-down warning circuitry
Power good circuitry
Delay time for PSON and PG signals
Remote ON/OFF function
On-Chip oscillator and Error amplifier
Latching PWM for cycle-by-cycle switching
Soft-start
Maximum 48% duty cycle
APPLICATIONS
Switching mode power supplies for computers such as ATX, NLX, and SFX micro-ATX.
