SC16M1TK6概述

SOURIAU  SC16M1TK6  圆形连接器触点, 冲压, 母, 18 AWG, 16 AWG, 压接, 镀锡触芯, Trim Trio系列

Trim Trio系列圆形是一款高可靠性, 多用途标准化连接器, 适用于广泛的互连应用. 互连系统是一个完全集成的系统, 其中4种触芯类型可用于多种连接器类型和尺寸, 范围从1至104个接触位置. 这种互换性提供了无限的设计可能性, 在整个产品系列具有很大的共性. 该产品参考MIL-C-26482, 输入和输出连接可以选择多种不同的尺寸.


欧时:
Female stamped and formed crimp contact,


得捷:
CONN SOCKET 16-18AWG TIN CRIMP


贸泽:
标准环形接头 Trim Trio Socket 16 AWG Contact Sz 16


e络盟:
圆形连接器触点, 冲压, Trim Trio系列, 母, 压接, 16 AWG, 18 AWG, TRIM TRIO圆形连接器


艾睿:
Never worry about a poor connection with this SC16M1TK6 connector contact from Souriau. It has a straight body orientation. It has a socket type gender. This device has a maximum current rating of 13 A. This has a Connector Rectangular connector. It uses the crimp termination method. Its wire is 16-18 AWG. This product is 19 mm long.


Allied Electronics:
CONTACT SOCKET 16-18AWG CRIMP


Chip1Stop:
Contact SKT Crimp ST Cable Mount Reel


Newark:
# SOURIAU  SC16M1TK6  Circular Connector Contact, Stamped, Socket, 18 AWG, 16 AWG, Crimp, Tin Plated Contacts


SC16M1TK6中文资料参数规格
技术参数

极性 Female

线规 16AWG ~ 18AWG

触点电镀 Tin

额定电流Max 13 A

接触电阻Max 6 mΩ

物理参数

触点材质 Copper Alloy

材质 Copper Alloy

其他

产品生命周期 Active

包装方式 Tape & Reel TR

制造应用 Aerospace, Defence, Military, 军用与航空, 工业, Industrial, 国防

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

REACH SVHC标准 No SVHC

军工级 Yes

数据手册

在线购买SC16M1TK6
型号: SC16M1TK6
制造商: Souriau 苏里奥
描述:SOURIAU  SC16M1TK6  圆形连接器触点, 冲压, 母, 18 AWG, 16 AWG, 压接, 镀锡触芯, Trim Trio系列
替代型号SC16M1TK6
型号/品牌 代替类型 替代型号对比

SC16M1TK6

Souriau 苏里奥

当前型号

当前型号

SC16ML-1TK6

苏里奥

完全替代

SC16M1TK6和SC16ML-1TK6的区别
