SN74AHCU04DRG4

六路反向器 HEX INVERTERS

description/ordering information

The ’AHCU04 devices contain six independent inverters. These devices perform the Boolean function Y = A. Internal circuitry consists of single-stage inverters that can be used in analog applications such as crystal oscillators.

• Operating Range 2-V to 5.5-V VCC

• Unbuffered Outputs

• Latch-Up Performance Exceeds 250 mA Per JESD 17

• ESD Protection Exceeds JESD 22

   − 2000-V Human-Body Model A114-A

   − 200-V Machine Model A115-A

   − 1000-V Charged-Device Model C101
