SSM-114-L-DV

Conn Socket Strip SKT 28POS 2.54mm Solder ST SMD Tube

28 位置 插座，通透式 0.100"（2.54mm） 表面贴装型 镀金

得捷:
CONN RCPT 28POS 0.1 GOLD SMD

艾睿:
Support physical configuration options for jumper posts by mounting this socket strip SSM-114-L-DV header connector from Samtec. This SKT connector&s;s 28 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 510 VDC|360VAC. It has a socket type gender. Its pitch is 2.54 mm. It has a straight body orientation. This is a 2-row connector. This device has a maximum current rating of 5.2 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. SSM-114-L-DV is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 35.56 mm long, 7.37 mm tall and 7.04 mm deep.

安富利:
Conn Socket Strip SKT 28 POS 2.54mm Solder ST SMD Tube

Verical:
Conn Socket Strip SKT 28 POS 2.54mm Solder ST Top Entry SMD Tube

Newark:
# SAMTEC  SSM-114-L-DV  Board-To-Board Connector, 2.54 mm, 28 Contacts, Receptacle, SSM Series, Surface Mount, 2 Rows

Online Components:
Conn Socket Strip SKT 28 POS 2.54mm Solder ST SMD Tube

Electro Sonic:
Conn Socket Strip SKT 28 POS 2.54mm Solder ST SMD Tube
