SSW-105-01-S-S

Conn Socket Strip SKT 5POS 2.54mm Solder ST Thru-Hole

5 Position Receptacle Connector Through Hole

欧时:
.100" Tiger Buy Socket Strip

得捷:
CONN RCPT 5POS 0.1 GOLD PCB

艾睿:
Samtec&s;s socket strip SSW-105-01-S-S header connector is a great way to reduce safety concerns in projects where there is a possibility of accidentally shorting electronic components. This SKT connector&s;s 5 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 1-row connector. It has a straight body orientation. It has a socket type gender. It has a maximum voltage rating of 550 VAC. Its pitch is 2.54 mm. This device has a maximum current rating of 5.7 A/contact. This connector has an operating temperature of -55 to 125 °C. This product is 13.21 mm long, 8.51 mm tall and 2.41 mm deep. SSW-105-01-S-S is housed in black liquid crystal polymer. It uses the solder termination method.

Verical:
Conn Socket Strip SKT 5 POS 2.54mm Solder ST Top Entry Thru-Hole Tube
