SQT-109-01-L-S

SAMTEC SQT-109-01-L-S Board-To-Board Connector, 2mm, 9Contacts, Receptacle, SQT Series, Through Hole, 1Rows

9 位置 插座 0.079"（2.00mm） 通孔 镀金

得捷:
CONN RCPT 9POS 0.079 GOLD PCB

欧时:
SOCKET 9POS 0.079 GOLD PCB

艾睿:
Mount this socket strip SQT-109-01-L-S header connector from Samtec on a jumper post on your PCB to support physical configuration options. This SKT connector&s;s 9 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 450 VAC. It has a socket type gender. This is a 1-row connector. It has a straight body orientation. Its pitch is 2 mm. This device has a maximum current rating of 5.1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. SQT-109-01-L-S is housed in black liquid crystal polymer. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. This product is 18.3 mm long, 6.35 mm tall and 2 mm deep.

Chip1Stop:
Conn Socket Strip SKT 9 POS 2mm Solder ST Thru-Hole Tube

Verical:
Conn Socket Strip SKT 9 POS 2mm Solder ST Thru-Hole Tube

Newark:
# SAMTEC  SQT-109-01-L-S  Board-To-Board Connector, 2 mm, 9 Contacts, Receptacle, SQT Series, Through Hole, 1 Rows
