SQT-112-01-L-D

Conn Socket Strip SKT 24POS 2mm Solder ST Thru-Hole Tube

24 位置 插座 0.079"（2.00mm） 通孔 镀金

欧时:
2.00 mm FleXYZ Cost-effective Tiger Buy

立创商城:
2mm

得捷:
CONN RCPT 24POS 0.079 GOLD PCB

艾睿:
Are you looking for a solution to support physical configuration options on your PCB? Then mount this socket strip SQT-112-01-L-D header connector from Samtec on your PCB today! This SKT connector&s;s 24 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a maximum voltage rating of 450 VAC. It has a socket type gender. It has a straight body orientation. Its pitch is 2 mm. This device has a maximum current rating of 5.1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. SQT-112-01-L-D is housed in black liquid crystal polymer. This product is 24.3 mm long, 6.35 mm tall and 4 mm deep. This connector has an operating temperature of -55 to 125 °C.

Newark:
# SAMTEC  SQT-112-01-L-D  Board-To-Board Connector, Through Hole, Receptacle, 24, 2 mm, Gold Plated Contacts
