SMP2-SGC概述

Bivar SMP2 Series LEDsThe SMP2 series, from Bivar, are in the industry standard PLCC-2 package. They offer a high luminous intensity alongside a wide viewing angle in a variety of colour options. The SMP2 LEDs have a compact, low profile package which is ideal for applications where space is limited. The PLCC-2 package is also robust and therefore suitable for use in a variety of environmental conditions. With long life reliability and low power consumption, the SMP2 series of LEDs are suitable for use in battery power equipment. Other suitable applications include illumination, general indication and backlighting. The SMP2 LEDs can also be used in clusters for high luminous applications. ### 可见光 LED,Bivar

SMP2 Series s

The SMP2 series, from Bivar, are in the industry standard PLCC-2 package. They offer a high luminous intensity alongside a wide viewing angle in a variety of colour options. The SMP2 LEDs have a compact, low profile package which is ideal for applications where space is limited. The PLCC-2 package is also robust and therefore suitable for use in a variety of environmental conditions. With long life reliability and low power consumption, the SMP2 series of LEDs are suitable for use in battery power equipment. Other suitable applications include illumination, general indication and backlighting. The SMP2 LEDs can also be used in clusters for high luminous applications.

### 可见光 LED,Bivar

SMP2-SGC中文资料参数规格
技术参数

额定功率 72 mW

针脚数 2

正向电压 1.9 V

波长 574 nm

发光强度 115 mcd

视角 120°

峰值波长 574 nm

测试电流 20 mA

正向电流 20 mA

工作温度Max 85 ℃

工作温度Min -40 ℃

封装参数

安装方式 Surface Mount

封装 PLCC-2

外形尺寸

长度 3.2 mm

宽度 2.8 mm

高度 2.00 mm

封装 PLCC-2

物理参数

颜色 Green

外观颜色 Transparent

其他

产品生命周期 Obsolete

包装方式 Tape & Reel TR

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买SMP2-SGC
型号: SMP2-SGC
制造商: Bivar
描述:Bivar SMP2 Series LEDs The SMP2 series, from Bivar, are in the industry standard PLCC-2 package. They offer a high luminous intensity alongside a wide viewing angle in a variety of colour options. The SMP2 LEDs have a compact, low profile package which is ideal for applications where space is limited. The PLCC-2 package is also robust and therefore suitable for use in a variety of environmental conditions. With long life reliability and low power consumption, the SMP2 series of LEDs are suitable for use in battery power equipment. Other suitable applications include illumination, general indication and backlighting. The SMP2 LEDs can also be used in clusters for high luminous applications. ### 可见光 LED,Bivar
替代型号SMP2-SGC
型号/品牌 代替类型 替代型号对比

SMP2-SGC

Bivar

当前型号

当前型号

SMTL2-SGC

Bivar

功能相似

SMP2-SGC和SMTL2-SGC的区别
