3 x 3 mm 140° 透明 120 mcd 3.5 V 替代 表面贴装 LED - SOT-23
Blue Indication - Discrete 3.5V TO-236, SC-59, SOT-23-3 variant, 3-SMD
得捷:
LED BLUE CLEAR SOT23 SMD
贸泽:
Standard LEDs - SMD SOT-23 Blue
富昌:
超级 蓝色 3 x 3 mm 140° 透明 120 mcd 3.5 V 替代 表面贴装 LED - SOT-23
Chip1Stop:
LED Uni-Color Blue 470nm 3-Pin SMD T/R
Newark:
# LUMEX SML-LX15USBC-TR LED, QuasarBrite, Blue, SMD, 3mm x 2mm, 20 mA, 3.5 V, 470 nm
Win Source:
LED BLUE CLEAR SOT23 SMD / Blue LED Indication - Discrete 3.5V TO-236, SC-59, SOT-23-3 variant, 3-SMD
额定功率 98 mW
正向电压 3.5 V
波长 470 nm
发光强度 120 mcd
视角 140°
透镜样式 Non-Diffused
峰值波长 470 nm
测试电流 20 mA
正向电流 20 mA
工作温度Max 85 ℃
工作温度Min 30 ℃
安装方式 Surface Mount
封装 SOT-23-3
长度 3 mm
宽度 3 mm
高度 1.00 mm
封装 SOT-23-3
颜色 Blue
外观颜色 Clear
产品生命周期 Discontinued at Digi-Key
包装方式 Cut Tape CT
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
