SLW-112-01-G-D

Conn Socket Strip SKT 24POS 2.54mm Solder ST Thru-Hole

24 Position Receptacle Connector 0.100" 2.54mm Through Hole Gold

欧时:
.100" Tiger Buy Skt Strip

得捷:
CONN RCPT 24POS 0.1 GOLD PCB

艾睿:
Mounting this socket strip SLW-112-01-G-D header connector from Samtec to your printed circuit board can help you support multiple physical configuration options. This SKT connector&s;s 24 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 50 VAC. Its pitch is 2.54 mm. It has a socket type gender. This is a 2-row connector. It has a straight body orientation. This device has a maximum current rating of 5.2 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. SLW-112-01-G-D is housed in black polyester. This product is 30.48 mm long, 4.57 mm tall and 4.95 mm deep. It uses the solder termination method.

安富利:
Conn Socket Strip SKT 24 POS 2.54mm Solder ST Thru-Hole

Verical:
SLW-112-01-G-D

Newark:
# SAMTEC  SLW-112-01-G-D  .050 MICRO STRIPS
