SLW-105-01-G-D

其他, .050 微型条

10 Position Receptacle Connector Through Hole

欧时:
.100" Tiger Buy Low Profile Socket Strip

得捷:
CONN RCPT 10POS 0.1 GOLD PCB

e络盟:
其他, .050 微型条

艾睿:
Easily mount this socket strip SLW-105-01-G-D header connector from Samtec onto your PCB project to support a variety of physical configuration options. This SKT connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a socket type gender. This is a 2-row connector. Its pitch is 2.54 mm. It has a straight body orientation. It has a maximum voltage rating of 50 VAC. This device has a maximum current rating of 5.2 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. SLW-105-01-G-D is housed in black polyester. This product is 12.7 mm long, 4.57 mm tall and 4.95 mm deep.

安富利:
Conn Socket Strip SKT 10 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  SLW-105-01-G-D  .050 MICRO STRIPS
