SSW-111-01-T-S

SAMTEC SSW-111-01-T-S Board-To-Board Connector, 2.54mm, 11Contacts, Receptacle, SSW Series, Through Hole, 1Rows

11 位置 插座 0.100"（2.54mm） 通孔 锡

欧时:
SOCKET 11POS 0.1 TIN PCB

得捷:
CONN RCPT 11POS 0.1 TIN PCB

艾睿:
Support physical configuration options for jumper posts by mounting this socket strip SSW-111-01-T-S header connector from Samtec. This SKT connector&s;s 11 contacts that are made out of phosphor bronze and plated with matte tin over nickel. This is a 1-row connector. Its pitch is 2.54 mm. It has a straight body orientation. It has a socket type gender. It has a maximum voltage rating of 550 VAC. This device has a maximum current rating of 5.7 A/contact. This connector has an operating temperature of -55 to 105 °C. SSW-111-01-T-S is housed in black liquid crystal polymer. This product is 28.45 mm long, 8.51 mm tall and 2.41 mm deep. It uses the solder termination method.

安富利:
Conn Socket Strip SKT 11 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Socket Strip SKT 11 POS 2.54mm Solder ST Top Entry Thru-Hole Tube

Newark:
# SAMTEC  SSW-111-01-T-S  Board-To-Board Connector, 2.54 mm, 11 Contacts, Receptacle, SSW Series, Through Hole, 1 Rows
