SOURIAU SMS12RE-4TR29 Wire-To-Board Connector, 5.08mm, 12Contacts, Receptacle, Qikmate SMS Series, Through Hole, 3Rows
"s qikmate USB connector can make a durable, rugged connection between different electronic components. It has a straight body orientation. This male connector"s 6 contacts that are made out of copper alloy and plated with gold. Its pitch is 5.08 mm. It has a receptacle type gender. SMS12RE-4TR29 is housed in polyester. This device has a maximum current rating of 5 A. It uses the solder termination method. This product is 16 mm deep. This harting connector has an operating temperature of -55 to 125 °C.
触点数 12
极性 Male
触点电镀 Tin
额定电流 5 A
绝缘电阻 5000 MΩ
排数 4
易燃性等级 UL 94 V-2
针脚数 12
接触电阻 6.00 mΩ
额定电流Max 5 A
工作温度Max 125 ℃
工作温度Min -55 ℃
接触电阻Max 6 mΩ
安装方式 Through Hole
高度 17.6 mm
颜色 Black
触点材质 Copper Alloy
材质 Nylon
工作温度 -55℃ ~ 125℃
产品生命周期 Active
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Contains Lead
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
