SQW-113-01-L-D

SAMTEC  SQW-113-01-L-D  板至板连接, SQW Series, 26 触点, 插座, 2 mm, 通孔安装, 2 排 新

26 Position Receptacle Connector 0.079" 2.00mm Through Hole Gold

欧时:
Rugged PCB Skts 2.00mm

立创商城:
2mm

得捷:
CONN RCPT 26POS 0.079 GOLD PCB

e络盟:
板至板连接, 2 mm, 26 触点, 插座, SQW Series, 通孔安装, 2 排

艾睿:
Samtec&s;s socket strip SQW-113-01-L-D header connector is a great way to reduce safety concerns in projects where there is a possibility of accidentally shorting electronic components. This SKT connector&s;s 26 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a maximum voltage rating of 500 VAC. Its pitch is 2 mm. It has a straight body orientation. It has a socket type gender. This device has a maximum current rating of 3.8 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 26.12 mm long, 6.35 mm tall and 4 mm deep. It uses the solder termination method. SQW-113-01-L-D is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Socket Strip SKT 26 POS 2mm Solder ST Thru-Hole Tube

Newark:
# SAMTEC  SQW-113-01-L-D  Board-To-Board Connector, 2 mm, 26 Contacts, Receptacle, SQW Series, Through Hole, 2 Rows
