SMS-110-01-S-D

SAMTEC SMS-110-01-S-D Board-To-Board Connector, 1.27mm, 20Contacts, Receptacle, SMS Series, Through Hole, 2Rows

20 位置 插座 0.050"（1.27mm） 通孔 镀金

得捷:
CONN RCPT 20POS 0.05 GOLD PCB

艾睿:
Use this socket strip SMS-110-01-S-D connector from Samtec when board-to-board interconnects is required. This SKT connector&s;s 20 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. This is a 2-row connector. It has a socket type gender. Its pitch is 1.27 mm. This device has a maximum current rating of 5 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. This product is 12.7 mm long, 8.51 mm tall and 5.59 mm deep. SMS-110-01-S-D is housed in liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Socket Strip SKT 20 POS 1.27mm Solder ST Thru-Hole Tube

Chip1Stop:
Conn Socket Strip SKT 20 POS 1.27mm Solder ST Thru-Hole Tube

Newark:
# SAMTEC  SMS-110-01-S-D  Board-To-Board Connector, 1.27 mm, 20 Contacts, Receptacle, SMS Series, Through Hole, 2 Rows

Online Components:
Conn Socket Strip SKT 20 POS 1.27mm Solder ST Thru-Hole Tube

Electro Sonic:
Conn Socket Strip SKT 20 POS 1.27mm Solder ST Thru-Hole Tube
