SLW-130-01-T-D

SAMTEC SLW-130-01-T-D Board-To-Board Connector, 2.54mm, 60Contacts, Receptacle, SLW Series, Through Hole, 2Rows

60 Position Receptacle Connector Through Hole

得捷:
CONN RCPT 60POS 0.1 TIN PCB

艾睿:
Are you looking for a solution to support physical configuration options on your PCB? Then mount this socket strip SLW-130-01-T-D header connector from Samtec on your PCB today! This SKT connector&s;s 60 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a socket type gender. Its pitch is 2.54 mm. This is a 2-row connector. It has a straight body orientation. It has a maximum voltage rating of 50 VAC. This device has a maximum current rating of 5.2 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. This connector has an operating temperature of -55 to 105 °C. SLW-130-01-T-D is housed in black polyester. This product is 76.2 mm long, 4.57 mm tall and 4.95 mm deep.

Newark:
# SAMTEC  SLW-130-01-T-D  Board-To-Board Connector, 2.54 mm, 60 Contacts, Receptacle, SLW Series, Through Hole, 2 Rows
