SLW-125-01-S-S

SAMTEC SLW-125-01-S-S Board-To-Board Connector, 2.54mm, 25Contacts, Receptacle, SLW Series, Through Hole, 1Rows

25 位置 插座 0.100"（2.54mm） 通孔 镀金

得捷:
CONN RCPT 25POS 0.1 GOLD PCB

艾睿:
Safety is an important concern when designing electronic devices. Samtec&s;s socket strip SLW-125-01-S-S header connector helps protect your equipment from accidental shortages. This SKT connector&s;s 25 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 1-row connector. It has a straight body orientation. It has a maximum voltage rating of 50 VAC. It has a socket type gender. Its pitch is 2.54 mm. This device has a maximum current rating of 5.2 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. This product is 63.5 mm long, 4.57 mm tall and 2.54 mm deep. SLW-125-01-S-S is housed in black polyester. It uses the solder termination method.

Newark:
# SAMTEC  SLW-125-01-S-S  Board-To-Board Connector, 2.54 mm, 25 Contacts, Receptacle, SLW Series, Through Hole, 1 Rows
