SQW-109-01-L-D

SAMTEC SQW-109-01-L-D Board-To-Board Connector, 2mm, 18Contacts, Receptacle, SQW Series, Through Hole, 2Rows

18 位置 插座 0.079"（2.00mm） 通孔 镀金

立创商城:
2mm

得捷:
CONN RCPT 18POS 0.079 GOLD PCB

艾睿:
Support physical configuration options for jumper posts by mounting this socket strip SQW-109-01-L-D header connector from Samtec. This SKT connector&s;s 18 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2 mm. This is a 2-row connector. It has a socket type gender. It has a maximum voltage rating of 500 VAC. It has a straight body orientation. This device has a maximum current rating of 3.8 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 125 °C. This product is 18.12 mm long, 6.35 mm tall and 4 mm deep. SQW-109-01-L-D is housed in black liquid crystal polymer. It uses the solder termination method.

安富利:
Conn Socket Strip SKT 18 POS 2mm Solder ST Thru-Hole Tube

Newark:
# SAMTEC  SQW-109-01-L-D  Board-To-Board Connector, 2 mm, 18 Contacts, Receptacle, SQW Series, Through Hole, 2 Rows
