SAMTEC SMM-140-01-S-D Board-To-Board Connector, 2mm, 80Contacts, Receptacle, SMM Series, Through Hole, 2Rows
80 Position Receptacle Connector Through Hole
得捷:
CONN RCPT 80POS 0.079 GOLD PCB
艾睿:
Support physical configuration options for jumper posts by mounting this socket strip SMM-140-01-S-D header connector from Samtec. This SKT connector&s;s 80 contacts that are made out of beryllium copper and plated with gold over nickel. It has a maximum voltage rating of 350 VAC. It has a straight body orientation. Its pitch is 2 mm. It has a socket type gender. This is a 2-row connector. This device has a maximum current rating of 3.2 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 80 mm long, 3.56 mm tall and 4 mm deep. SMM-140-01-S-D is housed in black liquid crystal polymer. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C.
Newark:
# SAMTEC SMM-140-01-S-D Board-To-Board Connector, 2 mm, 80 Contacts, Receptacle, SMM Series, Through Hole, 2 Rows
