SMM-130-02-S-S

SAMTEC SMM-130-02-S-S Board-To-Board Connector, 2mm, 30Contacts, Receptacle, SMM Series, Surface Mount, 1Rows

30 Position Receptacle Connector 0.079" 2.00mm Surface Mount Gold

得捷:
CONN RCPT 30POS 0.079 GOLD SMD

艾睿:
Look no further than the socket strip SMM-130-02-S-S header connector from Samtec, a great tool to use when board-to-board interconnects is required. This SKT connector&s;s 30 contacts that are made out of beryllium copper and plated with gold over nickel. This is a 1-row connector. Its pitch is 2 mm. It has a maximum voltage rating of 350 VAC. It has a socket type gender. It has a straight body orientation. This device has a maximum current rating of 3.2 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 60 mm long, 3.68 mm tall and 4.32 mm deep. It uses the solder termination method. SMM-130-02-S-S is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C.

Newark:
# SAMTEC  SMM-130-02-S-S  Board-To-Board Connector, 2 mm, 30 Contacts, Receptacle, SMM Series, Surface Mount, 1 Rows
