SLW-134-01-S-D

SAMTEC SLW-134-01-S-D Board-To-Board Connector, 2.54mm, 68Contacts, Receptacle, SLW Series, Through Hole, 2Rows

68 Position Receptacle Connector Through Hole

得捷:
CONN RCPT 68POS 0.1 GOLD PCB

艾睿:
Easily mount this socket strip SLW-134-01-S-D header connector from Samtec onto your PCB project to support a variety of physical configuration options. This SKT connector&s;s 68 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. It has a socket type gender. Its pitch is 2.54 mm. This is a 2-row connector. It has a maximum voltage rating of 50 VAC. This device has a maximum current rating of 5.2 A/contact. It uses the solder termination method. This product is 86.36 mm long, 4.57 mm tall and 4.95 mm deep. SLW-134-01-S-D is housed in black polyester. This connector has an operating temperature of -55 to 125 °C.

Newark:
# SAMTEC  SLW-134-01-S-D  Board-To-Board Connector, 2.54 mm, 68 Contacts, Receptacle, SLW Series, Through Hole, 2 Rows
