SAMTEC SFM-125-01-S-D-LC Wire-To-Board Connector, 1.27mm, 50Contacts, Receptacle, SFM Series, Through Hole, 2Rows
50 Position Receptacle Connector 0.050" 1.27mm Through Hole Gold
得捷:
CONN RCPT 50POS 0.05 GOLD PCB
艾睿:
Reduce safety concerns with this socket strip SFM-125-01-S-D-LC header connector from Samtec which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This SKT connector&s;s 50 contacts that are made out of beryllium copper and plated with gold over nickel. It has a maximum voltage rating of 250 VAC. This is a 2-row connector. It has a socket type gender. Its pitch is 1.27 mm. It has a straight body orientation. This device has a maximum current rating of 3.2 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 125 °C. SFM-125-01-S-D-LC is housed in black liquid crystal polymer. It uses the solder termination method. This product is 35.69 mm long, 4.57 mm tall and 3.68 mm deep.
Newark:
# SAMTEC SFM-125-01-S-D-LC Wire-To-Board Connector, 1.27 mm, 50 Contacts, Receptacle, SFM Series, Through Hole, 2 Rows
