SLF12575T-2R7N7R0-H

2.7uH ±30% 7A 编带

2.7 µH 屏蔽 鼓芯，绕线式 器 7 A 8.88 毫欧最大 非标准

得捷:
FIXED IND 2.7UH 7A 8.88 MOHM SMD

立创商城:
2.7uH ±30% 7A 7.4mΩ

贸泽:
固定电感器 2.7uH 7.0A AEC-Q200

艾睿:
This power SLF12575T-2R7N7R0-H surface mount inductor from TDK is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. Its test frequency is 1K Hz. This product is 12.8 mm long, 7.85 mm tall and 12.8 mm deep. This device is made with wirewound technology. This SMD inductor has a maximum DC current of 7Typ A with a maximum resistance of 8.88m Ohm. It has an inductance of 2.7u H.

Chip1Stop:
Ind Power Shielded Wirewound 2.7uH 30% 1KHz 7A T/R

Electro Sonic:
Inductor Power Shielded Wirewound 2.7uH 30% 1KHz Ferrite 7A 8.88mOhm DCR Automotive T/R

Win Source:
2.7μH Shielded Wirewound Inductor 7A 8.88 mOhm Max Nonstandard
