SSW-136-02-S-D-RA

Conn Socket Strip SKT 72POS 2.54mm Solder RA Thru-Hole

72 Position Receptacle Connector Through Hole, Right Angle

得捷:
CONN RCPT 72POS 0.1 GOLD PCB R/A

艾睿:
Reduce the possibility of accidentally shorting pins when using a printed circuit board with this socket strip SSW-136-02-S-D-RA header connector from Samtec. This SKT connector&s;s 72 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a right angle body orientation. It has a socket type gender. This is a 2-row connector. It has a maximum voltage rating of 550 VAC. Its pitch is 2.54 mm. This device has a maximum current rating of 5.7 A/contact. This product is 91.95 mm long, 4.95 mm tall and 12.57 mm deep. It uses the solder termination method. SSW-136-02-S-D-RA is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Socket Strip SKT 72 POS 2.54mm Solder RA Thru-Hole

Verical:
Conn Socket Strip SKT 72 POS 2.54mm Solder RA Side Entry Thru-Hole Layer
