STPS30H100CT

STMICROELECTRONICS  STPS30H100CT  肖特基整流器, 双共阴极, 100 V, 15 A, TO-220AB, 3 引脚, 800 mV

阵列 1 对共阴极 肖特基 100 V 15A 通孔 TO-220-3

得捷:
DIODE ARRAY SCHOTTKY 100V TO220

立创商城:
100V 15A 800mV@15A

艾睿:
If your circuit needs to adjust from an AC to DC voltage use a Schottky diode STPS30H100CT rectifier from STMicroelectronics. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It is made in a dual common cathode configuration. Its peak non-repetitive surge current is 250 A, while its maximum continuous forward current is 30 A. This rectifier has an operating temperature range of -40 °C to 175 °C.

安富利:
Diode Schottky 100V 30A 3-Pin3+Tab TO-220AB Tube

富昌:
STPS30H100C Series 100VDC Reverse High Voltage Power Schottky Rectifier TO-220AB

Chip1Stop:
Diode Schottky 100V 30A 3-Pin3+Tab TO-220AB Tube

Verical:
Rectifier Diode Schottky 100V 30A 3-Pin3+Tab TO-220AB Tube

Newark:
Schottky Rectifier, 100 V, 15 A, Dual Common Cathode, TO-220AB, 3 Pins, 800 mV

Win Source:
DIODE ARRAY SCHOTTKY 100V TO220
