Power N-CH 60V 44A
表面贴装型 N 通道 60 V 35A（Tc） 5W（Ta），80W（Tc） PowerFlat™（5x6）
得捷:
MOSFET N-CH 60V 35A POWERFLAT
艾睿:
Amplify electronic signals and switch between them with the help of STMicroelectronics&s; STL35N6F3 power MOSFET. Its maximum power dissipation is 80000 mW. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This N channel MOSFET transistor operates in enhancement mode. This MOSFET transistor has an operating temperature range of -55 °C to 175 °C.
Chip1Stop:
Trans MOSFET N-CH 60V 44A 8-Pin Power Flat T/R
DeviceMart:
MOSFET N-CH 60V 44A POWERFLAT
Win Source:
MOSFET N-CH 60V 44A POWERFLAT
极性 N-CH
耗散功率 5W Ta, 80W Tc
漏源极电压Vds 60 V
连续漏极电流Ids 44A
上升时间 2.9 ns
输入电容Ciss 762pF @25VVds
额定功率Max 80 W
下降时间 4 ns
工作温度Max 175 ℃
工作温度Min -55 ℃
耗散功率Max 5W Ta, 80W Tc
安装方式 Surface Mount
引脚数 8
封装 PowerVDFN-8
封装 PowerVDFN-8
工作温度 -55℃ ~ 175℃ TJ
产品生命周期 Not Recommended for New Designs
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
