N沟道30 V , 0.0042 I© , 75 A, DPAK , TO- 220 , IPAK ,短IPAK N-channel 30 V, 0.0042 Ω, 75 A, DPAK, TO-220, IPAK, Short IPAK
N-Channel 30V 75A Tc 60W Tc Surface Mount DPAK
得捷:
MOSFET N-CH 30V 75A DPAK
艾睿:
As an alternative to traditional transistors, the STD75N3LLH6 power MOSFET from STMicroelectronics can be used to both amplify and switch electronic signals. Its maximum power dissipation is 60000 mW. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This MOSFET transistor has an operating temperature range of -55 °C to 175 °C. This device utilizes stripfet vi technology. This N channel MOSFET transistor operates in enhancement mode.
Chip1Stop:
Trans MOSFET N-CH 30V 75A 3-Pin2+Tab DPAK T/R
DeviceMart:
MOSFET N-CH 30V 75A DPAK
Win Source:
MOSFET N-CH 30V 75A DPAK
漏源极电阻 0.0042 Ω
极性 N-Channel
耗散功率 60 W
阈值电压 1.7 V
漏源极电压Vds 30 V
上升时间 30 ns
输入电容Ciss 1690pF @25VVds
额定功率Max 60 W
下降时间 12 ns
工作温度Max 175 ℃
工作温度Min -55 ℃
耗散功率Max 60W Tc
安装方式 Surface Mount
引脚数 3
封装 TO-252-3
封装 TO-252-3
工作温度 -55℃ ~ 175℃ TJ
产品生命周期 Not Recommended for New Designs
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
STD75N3LLH6 ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
STD18N55M5 意法半导体 | 类似代替 | STD75N3LLH6和STD18N55M5的区别 |
STD15NF10T4 意法半导体 | 类似代替 | STD75N3LLH6和STD15NF10T4的区别 |
STD86N3LH5 意法半导体 | 类似代替 | STD75N3LLH6和STD86N3LH5的区别 |
