Power Supply; AC-DC; 48V; 10A; 100-264V In; Enclosed; DIN Rail; PFC; 480W; SDR Series
**Features:
* **High Efficiency Up to 94% — SDR240 and SDR480
* Universal Input/Full Range
* Built-In Active PFC Function, PF>0.93
* Protections: Short Circuit, Overload, Over Voltage, Over Temperature
* Cooling by Free Air Convection
* Can Be Installed on DIN Rail TS-35, 7.5, or 15
* UL 508 Approved
* EN61000-6-2EN50082-2 Industrial Immunity Level
* Built-In DC OK Relay Contact
* 150% Peak Load Capability
* Comply with GL and SEMI F47
* Current Sharing 7+1 for SDR-480P
* 3-Year Factory Warranty
额定功率 480 W
输出接口数 1
输出电压 48 V
输出电流 10 A
输出功率 480 W
输入电压DC Max 370 V
输入电压DC Min 127 V
输入电压AC Max 264 V
输入电压AC Min 90 V
输出电流Max 10 A
输入电流Min 5 A
输出功率Max 480 W
工作温度Max 70 ℃
工作温度Min -25 ℃
电源电压 90.264VAC, 127.370VDC
输入电压 100VAC ~ 264VAC
安装方式 DIN Rail
引脚数 11
长度 128.5 mm
宽度 85.5 mm
高度 125.2 mm
颜色 Silver
重量 1.6 kg
工作温度 -25℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
制造应用 危险场所，ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8504409530
