4.7mF 10V
Radial Leaded Aluminum Capacitor, -40 to +85°C Operating Temperature, 500 hr Shelf Life
The SK series is a radial lead, high CV miniature aluminum electrolytic capacitor which is smaller in case size than other general use products. This series is suitable for those electronic products requiring smaller capacitors. It is suitable for consumer electronic equipment, such as stereo radios, TV sets, etc. The aluminum case is enclosed in a vinyl sleeve.- .
- * Tolerance:** ±20%. ** Operating Temperature Range:** -40 ~ +85°C.
* Meets RoHS Lead Free Definition
额定电压DC 10.0 V
电容 4700 μF
等效串联电阻ESR 80.0 mΩ
容差 ±20 %
产品系列 SK
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压 10 VDC
安装方式 Radial
引脚数 2
封装 Radial, Can
长度 25 mm
高度 25.0 mm
直径 16.0 mm
脚长度 15 mm
封装 Radial, Can
介质材料 Aluminum Electrolytic
工作温度 85 ℃
产品生命周期 Active
包装方式 Bulk
寿命（小时） 2000h @85℃
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
SK472M010ST Cornell Dubilier ElectronicsCDE | 当前型号 | 当前型号 |
NRSA472M10V16X25F NIC | 功能相似 | SK472M010ST和NRSA472M10V16X25F的区别 |
NRSA472M10V16X25TRF NIC | 功能相似 | SK472M010ST和NRSA472M10V16X25TRF的区别 |
ELLA100ELL472ML25S 贵弥功 | 功能相似 | SK472M010ST和ELLA100ELL472ML25S的区别 |
