SMART1500RM2U概述

TRIPP-LITE SMART1500RM2U Uninterruptible Power Supply UPS, Rack Mount, 1.5kVA / 1kW, 8Outlets, 147V, 120VAC, 5.3 min

Tripp Lite"s SMART 1500RM2U intelligent, line-interactive sine wave rack/tower uninterruptible power supply prevents data loss, downtime and equipment damage due to power outages, voltage fluctuations and transient surges. Requires only two rack spaces 2U in a standard rack enclosure. Large internal batteries offer 19 minutes half load runtime and 7 minutes at full load. Maintains regulated 120 V nominal output without using battery power during brownouts and overvoltages from 83 to 147 V. 1500 VA/1000 watt power handling capability and full time sine wave output supports networking, telecom and other sensitive electronic applications. Includes a total of 8 outlets arranged in 2 load banks that are individually controllable by a software interface to reboot select equipment on demand or shed less significant loads to extend battery runtime for more critical equipment. Supports simultaneous remote monitoring of UPS and site power conditions via built-in USB and DB9 monitoring ports. Optional SNMPWEBCARD accessory enables remote monitoring of UPS as a managed device via network management console applications. Communications ports support messaging of detailed UPS operational parameters and line power status. Includes PowerAlert UPS monitoring and unattended shutdown software with management support for an unlimited number of network UPS systems. Built-in accessory slot supports SNMP with optional SNMPWEBCARD adapter. Emergency Power Off EPO interface offers option for instantaneous power-off of UPS and connected equipment in the case of fire or emergency. Multi-function audible alarms and set of 5 front panel LEDs offer at-a-glance notification of UPS and line power status. Network-grade AC surge suppression protects equipment from damage and performance problems resulting from transient surges and line noise. Attractive all-black color scheme. Two year warranty with $250,000 connected equipment insurance USA & Canada only.

**_Package Includes:_**

* SMART 1500RM2U UPS System

* Mounting hardware for 4 post rackmount installation

* Cabling for USB and DB9 monitoring and EPO switching

* PowerAlert unattended shutdown and UPS/Power monitoring software

* Warranty information and instruction manual

**Features:**

* SMART 1500RM2U line-interactive UPS offers battery derived sine wave AC output during power outages, voltage regulation during brownouts and overvoltages, plus network grade AC surge suppression

* 1500 VA/1000 watt power handling ability and full time sine wave output offers guaranteed compatibility with properly sized networking,

telecom and other sensitive electronic devices

SMART1500RM2U中文资料参数规格
技术参数

频率 60.0 Hz

额定功率 1350 W , 1500 VA

输出电压 120 V

输出功率 1500 VA

输入电压AC Max 147 v

工作温度Max 40 ℃

工作温度Min 0 ℃

电源电压 120 VAC

输入电压 120 V

封装参数

安装方式 Rack

外形尺寸

长度 2260.6 mm

宽度 11303 mm

高度 8712.2 mm

电源线长度 3.05 m

物理参数

颜色 Black

重量 20.9 kg

工作温度 0℃ ~ 40℃

其他

产品生命周期 Active

制造应用 网络,单相

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册
