SN74AC373DBRE4

八路D型透明锁存器带3态输出 OCTAL D-TYPE TRANSPARENT LATCHES WITH 3-STATE OUTPUTS

description

These 8-bit latches feature 3-state outputs designed specifically for driving highly capacitive or relatively low-impedance loads. The devices are particularly suitable for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers.

2-V to 6-V VCC Operation

Inputs Accept Voltages to 6V

Max tpdof 9.5 ns at 5V

3-State Noninverting Outputs Drive Bus Lines Directly

Full Parallel Access for Loading

贸泽:
闭锁 Tri-St Octal D-Type

艾睿:
Latch Transparent 3-ST 8-CH D-Type 20-Pin SSOP T/R
